Description
• HVSAmp Home Energy Storage System Series: With its modular design, the Multi-functional Energy Storage System offers endless possibilities.
• Customize the system to meet your specific needs by easily adding or removing energy storage units.
• Experience the freedom and control of managing your energy consumption with this state-of-the-art system.
▏Features
• Integrated energy storage system, to meet the application of microgrid;
• Small size, flexible deployment, easy transportation and maintenance;
• With classification society certification, meet the requirements of sea transport; • Unattended system, remote monitoring;
•Multiple configurations to meet different requirements;
•Complete certification and protection to meet the requirements of many national power grid
▏General Specifications
Model | HVSAMP4850 | HVSAMP48100 | HVSAMP48200 |
Nominal energy(kWh) | 5.12 | 10.24 | 15.36 |
Module Number | 1~6pcs | 1~6pcs | 1~6pcs |
Nominal voltage | 51.2V | ||
Chemistry | LiFePO4 | ||
Operatingvoltagerange | 40V-58.4V | ||
Max discharge/discharge current | 100A | 200A | 300A |
Communication method | CAN, RS485 | ||
ParallelsFunction | 1P | ||
Cycle life | >6000Cycles | ||
Operatingtemperaturerange | Charging:0-55℃ Discharging:-20-55℃ | ||
Protection level | IP20 | ||
Color | white/customizable | ||
Dimension | 621×223.5×600 | 621×233.5×1057 | 621×233.5×1557 |
Weight | 30kg/module | 50kg/module | 100kg/module |
Installation | Stack mounted/Floor type |
